KY-PI Tube/ Kapton Tube / High-temperature resistant PI medical conduit /Golden medical conduit /Golden polyimide medical tube
Product Overview：
- Product Features
- Specifications
- Technical data
- Video
-
KY-PI Sleeving / Polyimide High Temperature Tube /Kapton Tube , As a precise tube with special geometric size, electrical, mechanical and chemical properties, it can be used as a protective casing, such as space, organism and internal, underground, nuclear power station, and industrial facilities, and so on, such as space volume, high and low temperature environment, complex electrical apparatus and radiation environment. The insulation casing, the gas liquid tube and so on.
When PI medical conduit / Golden Medical Conduit Applied in the Medical field, KY-PI Tube can used for insulation protection of Medical POGO Pin, Medical Catheters etc.
-
KY-PI TUBE ( Kapton Tube ) can Customized specifications according to customer requirements,
Minimum specification is ID 0.1MM,
The largest specification inner diameter is 63.5MM now.
ID(mm) Inner diameter tolerance (mm) Single Wall
(mm)Out Diameter (mm) PACKING Φ0.2 0.2±0.02 0.02/0.04±0.01 Φ0.29 1M/PCS Φ0.25 0.25±0.02 0.02/0.04±0.01 Φ 0.34 1M/PCS Φ0.3 0.3±0.02 0.02/0.04±0.01 Φ0.39 1M/PCS Φ0.35 0.35±0.02 0.02/0.04±0.01 Φ0.44 1M/PCS Φ0.4 0.4±0.02 0.03/0.06土0.01 Φ0.48 1M/PCS Φ0.45 0.45±0.02 0.03±0.02 Φ0.51 1M/PCS Φ0.5 0.5±0.02 0.03/0.06±0.02 Φ0.63 1M/PCS Φ0.6 0.6±0.02 0.03/0.06±0.02 Φ0.72 1M/PCS Φ0.7 0.7±0.02 0.03/0.06土0.02 Φ0.83 1M/PCS Φ0.75 0.75±0.02 0.03±0.02 Φ0.83 1M/PCS Φ0.8 0.8±0.02 0.03/0.06±0.02 Φ0.92 1M/PCS Φ0.85 0.85±0.02 0.03±0.02 Φ0.95 1M/PCS Φ0.9 0.9±0.02 0.06±0.02 Φ1.03 1M/PCS Φ1.0 1.0±0.02 0.04/0.06±0.02 Φ1.13 1M/PCS Φ1.1 1.1±0.02 0.06±0.02 Φ1.23 1M/PCS Φ 1.2 1.2±0.02 0.03/0.06±0.02 Φ 1.33 1M/PCS Φ 1.3 1.3±0.02 0.06±0.02 Φ 1.43 1M/PCS Φ 1.5 1.5±0.02 0.06±0.02 Φ 1.63 1M/PCS Φ 1.6 1.6±0.02 0.06±0.02 Φ 1.73 1M/PCS Φ 2.0 2.0±0.02 0.06±0.02 Φ 2.13 1M/PCS Φ 2.5 2.5±0.02 0.06±0.02 Φ 2.63 1M/PCS Φ 3.0 3.0±0.02 0.06±0.02 Φ 3.13 1M/PCS The specifications and dimensions can be customized according to the customer's requirements
-
- Long-term temperature resistance can reach 250 ℃ .
- high temperature and low temperature resistance, low temperature non melting, high temperature at 400 degrees, no softening deformation, allowing 240 long term use.
- excellent electrical insulation, dielectric constant of about 3.4, and dielectric strength of not less than 120KV/mm.
- excellent mechanical properties, tensile strength of not less than 150MPa, elongation elongation of not less than 10%.
- stable chemical properties, resistant to all kinds of organic solvents except alkaline solutions.
- excellent radiation resistance, low release gas under thermal vacuum.
- the friction coefficient of material surface is about 0.5, which can be well bonded with many kinds of binders.
-
